FEATURES: Chassis: Nylon composite 0.08 (2mm) thick gray in color with
integrated and scalable dual battery compartments quick release
battery doors and cooling vents for constant airflow
Drive: Four wheel shaft drive
Motor: Twin Titan Fan Cooled 550 Motors
Radio: Traxxas TQ 2.4GHz with Traxxas Link Technology adjustable
exponential end points and sub-trim steering and braking dual
rates 5-channel Traxxas Link receiver
Ball Bearings: Full set
Shocks: Oil-filled hard-anodized teflon coated titanium-nitride
coated shafts
Gearbox: Closed
Differentials: Hardened steel bevel sealed
Transmission: One-speed brushless ready
Tires: 3.8 (97mm) rubber construction
Wheels: 3.8 (97mm) 5-spoke black chrome
Speed Control: EVX-2 with High-Current Traxxas Connectors
Bumpers: Front rear and center skid plate nylon construction
Suspension: Sealed pivot ball
Caster: Adjustable caster/toe-in refers to the angle of the front
front suspension when viewed from the side of the car in relation
to the chassis
Camber: Adjustable camber refers to the angle of the tops of the
tires from vertical when when viewed from front or behind vehicle
Steering Tie Rods: Front and rear adjustable 0-3 degrees
Steering: Bell-crank type
Batteries: Two 7-cell 8.4V 3000mAh stick battery packs with Traxxas
connectors


INCLUDES: Traxxas E-Revo Racing Monster Truck with two 550 size motors 2.4GHz
radio ESC painted body decals and instruction manual
_
REQUIRES: AA Batteries: Four for transmitter
Charger: NiMH capable peak detecting charger


SPECS: VEHICLE-
Length: 22.9 (582mm)
Width: 16.5 (419mm)
Height: 8.3 (210mm)
Weight: 9.5lbs (4330g) approimately without batteries
Wheelbase: 14 (358mm)
Front Track: 16.4 (416mm)
Rear Track: 16.5 (419mm)
Ground Clearance: 3.9 (99mm)


BODY-
Length: 19.9 (505mm)
Width: 7.29 (185mm) at rear wheels (widest point)
6.7 (170mm) behind from wheels (thinnest point)
Height: 4.9 (124mm)
