FEATURES: Chassis: Titanium anodized 6061-T6 aluminum 1/8 (3mm) thick 3D
semi-monocoque with integrated roll hoop and carry handle
Drive: Four wheel
Drive Type: Shaft driven shafts are .71 (18mm) diameter with
half shafts and rubber shielded stub axle bearings
Engine: Traxxas .20 cu in (3.3cc) racing engine with slide valve
carburetor and high flow dual stage air filter with 60 more peak
horsepower than the TRX 2.5 engine EZ-Start electric starter and
7.2V battery
Exhaust: Polished resonator dual chamber aluminum tuned pipe
Fuel Tank: Low profile 5.1oz (150cc) with flip top cap
Radio: Traxxas TQ 2.4GHz pistol grip with steering and throttle
sensitivity steering and braking percentage and Traxxas Link
technology that stores settings for up to 20 Traxxas Link enabled
models
Clutch: Two shoe composite construction
Transmission: Auto shifting wide ratio two speed forward only
Ball Bearings: Full set included rubber sealed bearings used in all
exposed locations
Shocks: 4 GTR inboard mounted maintenance free silicone oil-filled
hard anodized Teflon coated bodies with TiN shafts
Main Gear: 38 tooth molded plastic
Gearbox: Sealed front and rear
Bumpers: Flexible molded front and rear tube style
Suspension: Linkage based for long travel and precise tuning
adjustments and control
Differentials: Maintenance free sealed with silicone X-rings and
gaskets limited slip action can be tuned using different viscosity
oil
Brakes: Alloy calipers giant 1.6 (40mm) diameter drilled and vented
steel rotor and semi-metallic friction material
Tires: Multi terrain soft compound rubber 1.6 (42mm) wide 4.3
(109mm) diameter with foam inserts
Wheels: Beadlock design 5-spoke satin chrome finish 2.2 (56mm)
diameter 1.6 (41mm) wide
Body: Traxxas ProGraphix pre-painted and trimmed with decals applied
Bumpers: Front and rear plastic construction
Suspension: Variable progressive two rocker design suspension travel
not limited to length of shocks ride height suspension travel
and progressive rate can be adjusted totally independent of each
other rubber sealed pivot balls can be adjusted with included tool
without removing seals steel pivot ball retaining rings
Caster: Adjustable caster/toe-in refers to the angle of the front
suspension when viewed from the side of the car in relation to the
chassis
Camber: Adjustable camber refers to the angle of the tops of the
tires from vertical when when viewed from front or behind vehicle
Steering: Ball bearing enhanced with twin high-torque servos driving
a heavy-duty servo saver
Warranty: 30 day warranty on electronic components
Chassis and engine are warranted free from defects at the date of
purchase before use. No warranties are expressed or implied that
cover damage caused by normal use or wear or cover or imply
how long any chassis or engine part will last before requiring
replacement due to wear.


INCLUDES: Traxxas Slayer Pro 4WD truck w/ oil-filled shocks 3.3 engine EZ-
Start painted body tires wheels foam inserts 2.4GHz radio w/
digital ball bearing steering servo one standard servo 15T clutch
bell 38T spur gear tool set illustrated manual decals two air
filter elements filter oil engine setup DVD long travel rocker
and spring set 7.2V battery wall charger extra glow plug and
fuel bottle


REQUIRES: Fuel: Traxxas 10 -20 Top Fuel
AA Radio Batteries: 8 4 for transmitter 4 for receiver


SPECS: Vehicle-
Length: 22.36 (568mm)
Width: 11.65 (296mm)
Height: 8.43 (214mm)
Weight: 7.6lb (3430g)
Wheelbase: 12.7 (323mm)
Front and Rear Track: 11.65 (296mm) outer edges of tires
Front and Rear Tread: 9.5 (241mm) center of tires
Center Ground Clearance: 2.6 (67mm)
Body-
Length: 21.5 (546mm)
Width: 9.4 (238mm) behind front wheels narrowest point
11.4 (290mm) at rear wheels widest point
Height: 5.5 (139mm)
