FEATURES: Chassis: 6061-T6 aluminum .16 (4mm) thick blue in color heavy
duty braces
Drive: Four wheel shaft driven with Revo spec driveline including
sealed driveshafts pivot balls and axle carrier
Wheelie Bar: 4 snap-in adjustment positions to control degree of
wheelie action easily removable if additional control isn t needed
Radio: Traxxas TQ 2.4GHz Direct Sequence Spread Spectrum (DSSS)
programmable system with Traxxas Link automatic model recognition
that allows up to 20 Traxxas Link receivers and transmitters to be
bound transmitter automatically recalls settings for any
previously bound receiver
Engine: Traxxas .20 cu in (3.3cc) racing engine w/Slide Valve
Carburetor 12mm diameter IPS crankshaft high volume dual stage
air filter
Starter: EZ-Start electric starting system with Traxxas s exclusive
Smart-Start technology that monitors critical starting functions
sensing and diagnosing potential problems for easy starting every
time
Battery: Traxxas Power Cell
Battery Charger: AC powered
Exhaust: Maxx Resonator dyno tuned dual chamber polished tuned pipe
Brake: Semi metallic giant 1.6 (42mm) diameter
Tires: 6.3 (160mm) outer diameter 3.8 (96.5mm) inner diameter
all terrain Maxx
Wheels: Hurricane chrome wheels 3.8 (96.5mm) diameter 2.75 (70mm)
wide 14mm hex size
Transmission: Revo-Spec forward only two speed autoshifting
with skid plate optional reverse kit sold separately
Differential: Revo-Spec sealed front and rear
Ball Bearings: Full set rubber sealed
Fuel Tank: 4.2oz (125cc)
Body: Trimmed and painted
Shocks: Eight oil-filled Ultra with rubber pressure badders and
double O-ring seals up to ten shock mounting positions nearly
4 (102mm) travel
Caster: Adjustable caster/toe-in refers to the angle of the front
suspension when viewed from the side of the car in relation to the
chassis
Camber: Adjustable camber refers to the angle of the tops of the
tires from vertical when viewed from front or behind vehicle
Suspension: Sealed pivot ball WideMaxx independent
Steering: Heavy duty bellcrank steering with integrated servo saver
Skid Plates: Heavy-duty plastic front and rear


INCLUDES: New T-Maxx RTR 3.3 truck TRX 3.3 engine EZ Start
electric starter EZ Start battery charger fuel bottle extra
glow plug metric hex hardware air filter two decal sheets
setup DVD antenna tube painted body illustrated instruction
manual and 2.4GHz radio system


REQUIRES: AA Batteries: 4 for transmitter 4 for battery box
Fuel: 10 -20 or 33 Top Fuel from Traxxas 20 recommended for
break-in
Track Equipment


SPECS: Chassis;
Length: 21 (539mm)
Front Track: 16.4 (417mm)
Rear Track: 16.5 (417mm)
Height: 11 (277mm)
Center Ground Clearance: 4 (106mm)
Wheelbase: 13.2 (335mm)
Wheel Diameter: 3.8 (97mm)
Transmission: Auto two-speed forward
Body;
Length: 19.6 (499mm)
Width: 6.3 (158mm) ahead of front wheels narrowest point
Width: 8.2 (209mm) at rear wheels widest point
Height: 5.7 (145mm)
